Product description
WPX series electric thermostat incubator is suitable for the cultivation experiments of bacteria/microorganisms in industrial and mining enterprises, food processing, agriculture, biochemistry, biology and medicine.
Features

The electrothermal constant temperature incubator is composed of a box body and a temperature control system. The box body is made of high-quality mesh stainless steel, and the surface is sprayed and treated, which is beautiful in appearance, novel and corrosion resistant.
The liner is made of high quality stainless steel.
The temperature control system of the machine adopts microcomputer single-chip technology and liquid crystal display instrument, and has the functions of PID temperature controller, time setting, temperature difference correction, over-temperature alarm, etc. It has high precision temperature control and multi- function. The time setting range is: 0-9999 minutes.
The number of shelves and the height of the rack can be adjusted as required by the user.
The professionally designed air circulation system allows the heat generated by the bottom heater to enter the working chamber in a natural convection manner, thereby increasing the uniformity of temperature in the working chamber.
The door has a large viewing angle glass observation window, which is convenient for the user to observe. The door seal is made of silicone rubber to make it well sealed.
The printer and RS-485/232 interface can be added before ordering according to user's requirements.

The main technical parameters:
Power supply : 110V/220V 50/60HZ
Inner size : W360*D360*H400mm
Outer size : W465*D500*H695mm
Package size: W620*D610*H825mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5-65℃
Temperature fluctuation :±0.2℃
N.W: 30kg; G.W: 35kg
More Spec. 52L82L152L252L
Power supply : 110V/220V 50/60HZ
Inner size : W360*D360*H400mm
Outer size : W465*D500*H695mm
Package size: W620*D610*H825mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5-65℃
Temperature fluctuation :±0.2℃
N.W: 30kg; G.W: 35kg​

Model WPX-9052
WPX-9052B
WPX-9052BC
WPX-9082
WPX-9082B
WPX-9082BC
WPX-9152
WPX-9152B
WPX-9152BC
WPX-9252
WPX-9252B
WPX-9252BC
Application
WPX series electric thermostat incubator is suitable for the cultivation experiments of bacteria/microorganisms
in industrial and mining enterprises, food processing, agriculture, biochemistry, biology and medicine.
Air circulation type Natural convection
Performance Operating temperature range RT+5~65℃
Temperature resolution 0.1℃
Temperature fluctuation ±0.2℃
Temperature uniformity ±1℃
Structure Liner material B/BC: stainless steel; no B: steel plate
Shell material BC: stainless steel; no B/B: electrostatic spraying of cold rolled steel sheets
Insulation materials Polyurethane
Heating element
Alloy heating wire
Rated power
Vent Inner diameter 40mm, rear test port
Controller Temperature control Double-column digital tube, PID
Temperature setting Tap the  four buttons to set
Temperature display Actual temperature: digital tube display (line 1); set temperature: digital tube display (line 2)
Timing 0~9999 minutes (with timing function)
Running function Timed running, fixed value running, automatic stop
Program mode Optional
Sensor Cu50
Additional features Deviation correction, menu button lock, power failure
compensation, power failure memory
Safety equipment Over temperature alarm
Specification Inner size(W*D*H mm) 360*360*400 420*420*460 500*500*610 600*600*700
Outer size(W*D*H mm) 465*500*695 525*560*755 605*640*905 705*740*995
Package size(W*D*H mm) 620*610*825 680*670*885 760*750*1035 860*800*1125
Capacity 52L 82L 152L 252L
Partition load bearing 15KG
Maximum number of separator layers 11 layers 13 layers 16 layers 20 layers
Separator spacing 18mm
Voltage (50/60Hz) / rated current AC220V/1.4V AC220V/1.8A AC220V/2.3A AC220V/2.7A
N.W/G.W 30/35kg 35/42kg 40/49kg 48/57kg
Accessory Partition 2pcs
Optional device Separator, RS485 interface, printer, recorder, external communication, remote control,
program temperature controller, wireless SMS alarm, U disk data storage
Product page link Details Details Details Details

Model

WPX-9052
WPX-9052B
WPX-9052BC

WPX-9082
WPX-9082B
WPX-9082BC

WPX-9152
WPX-9152B
WPX-9152BC

WPX-9252
WPX-9252B
WPX-9252BC

Air circulation type

Natural convection

Inner size

(W*D*H mm)

360*360*400

420*420*460

500*500*610

600*600*700

Outer size

(W*D*H mm)

465*500*695

525*560*755

605*640*905

705*740*995

Rated power

Capacity

52L

82L

152L

252L

N.W./G.W.

30/35kg

35/42kg

40/49kg

48/57kg

Liner material

WPX: Steel plate; B/BC: Stainless steel

Shell material

WPX/B: electrostatic spraying of cold rolled steel; BC: Stainless steel

Operating temperature range

RT+5~65

Temperature fluctuation

±0.2

Timing

0~9999 minutes (with timing function)

Power supply

AC220V 50/60HZ


1. Can you customize the product?

Yes, we can customize any products according to customer’s requirements.

2. Which payment terms are you doing?

T/T (Bank telegraphic transfer,100% payment in advance.).
PayPal (Paypal only pay less than $500, and must be transported by Express.).
West Union.

3. Which shipment is available?

Sea freight, air transport, rail transport, international express or as your requirements.

4. Which country you have been exported?

Our products have been exported to many countries, more than 100 countries and regions around the world.

5. How long is the delivery time?

It’s about 7-20 days.

6、What trade methods do you offer?
The trade methods we support are FOB, FCA, CIF,EXW,DDU.
