Name：Thermostat heating incubator
Model：WPX-9052/9052B/9052BC
Product description
WPX series electric thermostat incubator is suitable for the cultivation experiments of bacteria/microorganisms in industrial and mining enterprises, food processing, agriculture, biochemistry, biology and medicine.
Features
The electrothermal constant temperature incubator is composed of a box body and a temperature control system. The box body is made of high-quality mesh stainless steel, and the surface is sprayed and treated, which is beautiful in appearance, novel and corrosion resistant.
The liner is made of high quality stainless steel.
The temperature control system of the machine adopts microcomputer single-chip technology and liquid crystal display instrument, and has the functions of PID temperature controller, time setting, temperature difference correction, over-temperature alarm, etc. It has high precision temperature control and multi- function. The time setting range is: 0-9999 minutes.
The number of shelves and the height of the rack can be adjusted as required by the user.
The professionally designed air circulation system allows the heat generated by the bottom heater to enter the working chamber in a natural convection manner, thereby increasing the uniformity of temperature in the working chamber.
The door has a large viewing angle glass observation window, which is convenient for the user to observe. The door seal is made of silicone rubber to make it well sealed.
The printer and RS-485/232 interface can be added before ordering according to user's requirements.
The main technical parameters:
Power supply : 110V/220V 50/60HZ
Inner size : W360*D360*H400mm
Outer size : W465*D500*H695mm
Package size: W620*D610*H825mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5-65℃
Temperature fluctuation :±0.2℃
N.W: 30kg; G.W: 35kg
Power supply : 110V/220V 50/60HZ
Inner size : W360*D360*H400mm
Outer size : W465*D500*H695mm
Package size: W620*D610*H825mm
Shelf : 2 layers
Average Power: 300 W
Temperature control range : RT+5-65℃
Temperature fluctuation :±0.2℃
N.W: 30kg; G.W: 35kg
| Model | WPX-9052 WPX-9052B WPX-9052BC | WPX-9082 WPX-9082B WPX-9082BC | WPX-9152 WPX-9152B WPX-9152BC | WPX-9252 WPX-9252B WPX-9252BC | |
| Application | WPX series electric thermostat incubator is suitable for the cultivation experiments of bacteria/microorganisms in industrial and mining enterprises, food processing, agriculture, biochemistry, biology and medicine. | ||||
| Air circulation type | Natural convection | ||||
| Performance | Operating temperature range | RT+5~65℃ | |||
| Temperature resolution | 0.1℃ | ||||
| Temperature fluctuation | ±0.2℃ | ||||
| Temperature uniformity | ±1℃ | ||||
| Structure | Liner material | B/BC: stainless steel; no B: steel plate | |||
| Shell material | BC: stainless steel; no B/B: electrostatic spraying of cold rolled steel sheets | ||||
| Insulation materials | Polyurethane | ||||
| Heating element | Alloy heating wire | ||||
| Rated power | |||||
| Vent | Inner diameter 40mm, rear test port | ||||
| Controller | Temperature control | Double-column digital tube, PID | |||
| Temperature setting | Tap the four buttons to set | ||||
| Temperature display | Actual temperature: digital tube display (line 1); set temperature: digital tube display (line 2) | ||||
| Timing | 0~9999 minutes (with timing function) | ||||
| Running function | Timed running, fixed value running, automatic stop | ||||
| Program mode | Optional | ||||
| Sensor | Cu50 | ||||
| Additional features | Deviation correction, menu button lock, power failure compensation, power failure memory | ||||
| Safety equipment | Over temperature alarm | ||||
| Specification | Inner size(W*D*H mm) | 360*360*400 | 420*420*460 | 500*500*610 | 600*600*700 |
| Outer size(W*D*H mm) | 465*500*695 | 525*560*755 | 605*640*905 | 705*740*995 | |
| Package size(W*D*H mm) | 620*610*825 | 680*670*885 | 760*750*1035 | 860*800*1125 | |
| Capacity | 52L | 82L | 152L | 252L | |
| Partition load bearing | 15KG | ||||
| Maximum number of separator layers | 11 layers | 13 layers | 16 layers | 20 layers | |
| Separator spacing | 18mm | ||||
| Voltage (50/60Hz) / rated current | AC220V/1.4V | AC220V/1.8A | AC220V/2.3A | AC220V/2.7A | |
| N.W/G.W | 30/35kg | 35/42kg | 40/49kg | 48/57kg | |
| Accessory | Partition | 2pcs | |||
| Optional device | Separator, RS485 interface, printer, recorder, external communication, remote control, program temperature controller, wireless SMS alarm, U disk data storage | ||||
| Product page link | Details | Details | Details | Details | |
| Model | WPX-9052 WPX-9052B WPX-9052BC | WPX-9082 WPX-9082B WPX-9082BC | WPX-9152 WPX-9152B WPX-9152BC | WPX-9252 WPX-9252B WPX-9252BC |
Internal dimensions (W*D*H mm) | 360*360*400 | 420*420*460 | 500*500*610 | 600*600*700 |
External dimensions (W*D*H mm) | 465*500*695 | 525*560*755 | 605*640*905 | 705*740*995 |
| Rated power | 0.3KW | 0.4KW | 0.5KW | 0.6KW |
| Capacity | 52L | 82L | 152L | 252L |
| N.W./G.W. | 30/35kg | 35/42kg | 40/49kg | 48/57kg |
| Air circulation type | Natural convection | |||
| Liner material | WPX: Steel plate; B/BC: Stainless steel | |||
| Shell material | WPX/B: electrostatic spraying of cold rolled steel; BC: Stainless steel | |||
| Operating temperature range | RT+5~65℃ | |||
| Temperature fluctuation | ±0.2℃ | |||
| Timing | 0~9999 minutes (with timing function) | |||
| Power supply | AC220V 50/60HZ | |||
Yes, all our dry cabinets and environmental chambers are fully customizable based on your technical specifications, capacity, materials (e.g., SUS304), and functional requirements (e.g., N₂ purge, heating, data logging).
• Standard models: 5–10 working days
• Customized configurations: 15–30 working days
Lead times may vary slightly based on order volume and component availability.
We offer flexible Incoterms® 2020 options to suit your logistics needs:
Note: DDU is no longer used in Incoterms® 2020; DAP is the current standard.
Shipping costs depend on product dimensions, weight, destination, and chosen transport method (sea, air, rail, or express). Import duties, VAT, GST, or other local taxes are typically the buyer’s responsibility unless DDP terms are selected. A detailed breakdown of all costs will be included in your official quotation.
Yes. We regularly export to clients worldwide and are experienced in handling international documentation, customs compliance, and global logistics coordination for industrial equipment.
